Product Name
CNC CONTROLLED CUTTING TABLES >>> MAXIGRAPH CNC GAS PLASMA CUTTING MACHINE
Description
Maxigraph -
CNC Gas Plasma Cutting Machine
Properties
  • High performance and efficiency to meet a wide range of requirements
  • 7 models available
  • Single side, dual side options
  • Well balanced and very responsive body
  • Rack and pinion drive is used for both axes
  • Highly accurate, smooth operation is assured thanks to precision machined steel rails and stable drive mechanism
  • Since 60 built-in patterns are provided, cutting can be performed simply by inputting dimensions
    • Files :
    Applications :

    Oxy-gas and plasma cutting CNC machine with cutting widths of 1,6 m, 2,1 m, 2,6 m, 3,1 m, 3,6 m, 4,1 m and any desired length.

    Technical Specs
    Cutting Speed 50-6000 mm/min
    Marking Speed 9000 mm/min
    Rapid Traverse 15000 mm/min
    Max no. Oxy-fuel Torch Sets (single drive) 4
    Max no. Oxy-fuel Torch Sets (dual drive) 6
    No of Plasma Torch Block 1
    Marking Station 1
    Standard Accessories Product Code Quantity
    Oxy-fuel Torch 1 pcs
    High Speed Cutting Tips 3 pcs / torch
    Optional Spares Product Code Quantity / Package
    Capasitive Height Sensor
    Marking Unit
    Automatic Ignition
